CC100 Standard – Single Head

Efficient, robust and competitive

A range of machines automatic using thermosyphon technology

CC 100 standard

  • Available in 1, 2 and 3 groups
  • Integrated rotative pump
  • Copper boiler
  • Thermosyphon system
  • Electric heating only
  • Boiler temperature controlled by PID system
  • Volumetric dosing
  • 2 pressure gauges : boiler pressure and pump pressure
  • 2x steams wands and 1x hot water (except 1 group: 2x steams wands and 1x hot water)
  • Automatic fill up of the boiler
  • Heating element protected by klixon
Category:

Description

Number of groups
1G
2G
3G
3G
Height (mm)
Depth (mm)
Width (mm)
500
512
400
500
512
704
500
512
919
500
512
919
Boiler capacity (l)
5
11
18
18
Power (W)
2600
3600
4700
6000
Voltage (V)
230*
230
230
400
Weight (kg)
40
58
72
72

* Option available on request : 110V or 400V

Colors available : black, white and red
noirblancrouge
